ALLENGERS X-RAY 100mA MACHINE
ALLENGERS-100 100mA-100KVP, full wave rectified x-ray generator with
Stationary anode x-ray tube as per BIS specifications.
OUTPUT 8KW as per BIS (IS: 7620-Part-I)
RATING – RADIOGRAPHY 100mA at 45 to 100 KVP;
50mA at 45 to 100 KVP;
25mA at 45 to 100 KVP.
KVP RANGE- 45 to 100KVP in steps of 5 KVP/step.
TIMER- Solid state electronic timer with timing range from 0.04 to
8 sec. in 24 steps.
CONTROL- Attractive and ergonomic designed control panel has digital display of mAs, KVP and radiographic mA. Independent voltmeter to indicate line voltage. mA meter, voltage compensator fine and coarse to compensate voltage is provided. Booster transformer is provided in control panel for stabilization of filament voltage. Tech. selector for selection of Radiographic mA, KVP selector from 45 to 100 and time selector switch for selection of radiographic time. Ready and x-ray switches, Bucky selector switch provided. Machine is made on/off with
Push to on/off type switches.
TUBE HEAD- Tube head can be tilted 360 degree with full flexibility for use in operation theaters and in ward for bedside radiography. Stationery anode x-ray tube, compact, heavy duty, full wave rectified high voltage tank consisting of H.T. transformer, filament transformer, high voltage silicon rectifiers, bushing all immersed in high grade transformer Oil and hermetically sealed.
ACCESSORIES ? Spare LBD bulb
? Set of fuses.
? User manual
? Dust cover
? Hand switch
? Touch up paints
STAND (CBM)- Mobile stand with 4-wheel design, which ensures easy
Mobility and steering. Counter balanced articulated tube carriage allowing smooth movements of the tube head in vertical and horizontal plane, lead lined cassette storage box. Double steel rope for counter balancing gives additional safety as per ISI-7620. Large castor nylon wheels for easy mobility. The stand is designed for
Maximum maneuverability of the unit.
POWER REQUIREMENT- Single phase 230 volts, AC, 50 Hz, maximum allowable
Line regulation ± 10% at line resistance of 0.4 ohms.
